CS 386: Lab Assignment 5

(TA in charge: Sohum Dhar)

Acknowledgement: This lab assignment is based on Project 4: Ghostbusters, which is a part of a recent offering of CS188 at UC Berkeley. The code and resources provided here are almost entirely drawn from the Berkeley project. We thank the authors at Berkeley for making their project available to the public.

GHOSTBUSTERS

Introduction

Pacman spends his life running from ghosts, but things were not always so. Legend has it that many years ago, Pacman's great grandfather Grandpac learned to hunt ghosts for sport. However, he was blinded by his power and could only track ghosts by their banging and clanging.

In this project, you will design Pacman agents that use sensors to locate and eat invisible ghosts. You'll advance from locating single, stationary ghosts to hunting packs of multiple moving ghosts with ruthless efficiency.

The code for this project contains the following files, available as a zip archive.

Files you'll edit:
bustersAgents.py Agents for playing the Ghostbusters variant of Pacman.
inference.py Code for tracking ghosts over time using their sounds.
Files you will not edit:
busters.py The main entry to Ghostbusters (replacing Pacman.py)
bustersGhostAgents.py New ghost agents for Ghostbusters
distanceCalculator.py Computes maze distances
game.py Inner workings and helper classes for Pacman
ghostAgents.py Agents to control ghosts
graphicsDisplay.py Graphics for Pacman
graphicsUtils.py Support for Pacman graphics
keyboardAgents.py Keyboard interfaces to control Pacman
layout.py Code for reading layout files and storing their contents
util.py Utility functions

Files to Edit and Submit: You will fill in portions of bustersAgents.py and inference.py during the assignment. You should submit these files with your code and comments. Please do not change the other files in this distribution or submit any of our original files other than these files.

You have been asked two questions (in bold), one each in Task 1 and Task 2. Provide answers to these questions in a file called descriptions.txt, which you should include in your submission.

Evaluation: Your code will be autograded for technical correctness. Please do not change the names of any provided functions or classes within the code, or you will wreak havoc on the autograder. However, the correctness of your implementation -- not the autograder's judgements -- will be the final judge of your score. If necessary, we will review and grade assignments individually to ensure that you receive due credit for your work.

Task 0: Ghostbusters and Bayes Nets (Ungraded)

In this version of Ghostbusters, the goal is to hunt down scared but invisible ghosts. Pacman, ever resourceful, is equipped with sonar (ears) that provides noisy readings of the Manhattan distance to each ghost. The game ends when Pacman has eaten all the ghosts. To start, try playing a game yourself using the keyboard.

python busters.py

The blocks of colour indicate where the each ghost could possibly be, given the noisy distance readings provided to Pacman. The noisy distances at the bottom of the display are always non-negative, and always within 7 of the true distance. The probability of a distance reading decreases exponentially with its difference from the true distance.

Your primary task in this assignment is to implement inference to track the ghosts. For the keyboard based game above, a crude form of inference was implemented for you by default: all squares in which a ghost could possibly be are shaded by the colour of the ghost. Naturally, we want a better estimate of the ghost's position. Fortunately, Bayes Nets provide us with powerful tools for making the most of the information we have. Throughout the rest of this project, you will implement algorithms for performing exact inference using Bayes Nets.

As you implement and debug your code, you may find it useful to run a single test at a time. In order to do this you will need to use the -t flag with the autograder. For example if you only want to run the first test of question 1, use this command.

python autograder.py -t test_cases/q1/1-ExactObserve

In general, all test cases can be found inside test_cases/q*.

Task 1 (3 marks): Exact Inference Observation

In this question, we have to help Pacman estimate ghost positions, so that Pacman can hunt them! For this task let's ignore the ghost's movement: that is, for modeling purposes, let's assume the ghost position doesn't change with time. We can model the ghost positions as a hidden variable in our BN and the noisy distance measurement as the observation variable. We update our belief distribution over the hidden variable (ghost position) on making new observations.

You will update the observe method in ExactInference class of inference.py to correctly update the agent's belief distribution over ghost positions given an observation from Pacman's sensors. A correct implementation should also handle one special case: when a ghost is eaten, you should place that ghost in its prison cell, as described in the comments of observe.

To run the autograder for this question and visualise the output, execute this command.

python autograder.py -q q1

As you watch the test cases, be sure that you understand how the squares converge to their final colouring. Question 1: In test cases where Pacman is boxed in (which is to say, he is unable to change his observation point), why does Pacman sometimes have trouble finding the exact location of the ghost?

Note: Your busters agents have a separate inference module for each ghost they are tracking. That's why if you print an observation inside the observe function, you'll only see a single number even though there may be multiple ghosts on the board.

Hints:

Task 2 (4 marks): Exact Inference with Time Elapse

In the previous question you implemented belief updates for Pacman based on his observations. Fortunately, Pacman's observations are not his only source of knowledge about where a ghost may be. Pacman also has knowledge about the ways that a ghost may move; namely that the ghost cannot move through a wall or more than one space in one time step.

To understand why this is useful to Pacman, consider the following scenario in which there is Pacman and one Ghost. Pacman receives many observations which indicate the ghost is very near, but then one which indicates the ghost is very far. The reading indicating the ghost is very far is likely to be the result of a buggy sensor. Pacman's prior knowledge of how the ghost may move will decrease the impact of this reading since Pacman knows the ghost could not move so far in only one move.

In this question, we want to model the evolution of hidden variable (ghost position) with time, given ghost action distribution. For this task the Pacman ignores the observations about its distance from ghosts. You will implement the elapseTime method in ExactInference. Your agent has access to the action distribution for any GhostAgent. In order to test your elapseTime implementation separately from your observe implementation in the previous question, this question will not make use of your observe implementation.

Since Pacman is not utilising any observations about the ghost, this means that Pacman will start with a uniform distribution over all spaces, and then update his beliefs according to how he knows the Ghost is able to move. Since Pacman is not observing the ghost, this means the ghost's actions will not impact Pacman's beliefs. Over time, Pacman's beliefs will come to reflect places on the board where he believes ghosts are most likely to be given the geometry of the board and what Pacman already knows about their valid movements.

For the tests in this question we will sometimes use a ghost with random movements and other times we will use the GoSouthGhost. This ghost tends to move south so over time, and without any observations, Pacman's belief distribution should begin to focus around the bottom of the board. To see which ghost is used for each test case you can look in the .test files.

To run the autograder for this question and visualise the output, use this command.

python autograder.py -q q2

As an example of the GoSouthGhostAgent, you can run

python autograder.py -t test_cases/q2/2-ExactElapse

and observe that the distribution becomes concentrated at the bottom of the board.

As you watch the autograder output, remember that lighter squares indicate that Pacman believes a ghost is more likely to occupy that location, and darker squares indicate a ghost is less likely to occupy that location. Question 2: For which of the test cases do you notice differences emerging in the shading of the squares? Can you explain why some squares get lighter and some squares get darker?

Hints:

Task 3 (3 marks): Exact Inference Full Test

Now that Pacman knows how to use both his prior knowledge and his observations when figuring out where a ghost is, he is ready to hunt down ghosts on his own. This question will use your observe and elapseTime implementations together, along with a simple greedy hunting strategy which you will implement for this question. In the simple greedy strategy, Pacman assumes that each ghost is in its most likely position according to its beliefs, then moves toward the closest ghost. Up to this point, Pacman has moved by randomly selecting a valid action.

Implement the chooseAction method in GreedyBustersAgent in bustersAgents.py. Your agent should first find the most likely position of each remaining (uncaptured) ghost, then choose an action that minimises the distance to the closest ghost. If correctly implemented, your agent should win the game in q3/3-gameScoreTest with a score greater than 700 at least 8 out of 10 times. Note: the autograder will also check the correctness of your inference directly, but the outcome of games is a reasonable sanity check.

To run the autograder for this question and visualise the output:

python autograder.py -q q3

Note: If you want to run this test (or any of the other tests) without graphics you can add the following flag:

python autograder.py -q q3 --no-graphics

Hints:

Submission

You're not done yet! Place all files which you've written code in or modified in a directory named 'la5-' appended by your roll number (say la5-12345678). Tar and Gzip the directory to produce a single compressed file (la5-12345678.tar.gz). It must contain the following files.

  1. bustersAgents.py
  2. inference.py
  3. descriptions.txt
  4. citations.txt (if applicable)
  5. Any other file that you have modified or created to solve this assignment
Submit this compressed file on Moodle, under Lab Assignment 05.
